| Code | 622201184 |
| Name | LIBRETA XS 3W SINGLE 24V/220V IP66 |
| System power, W | 3W |
| Input voltage, V | 24V, 220V |
| Color temp.,K | 2700 - 5700K, R,G,B |
| Dimensions | 50x63x100 |
| Weight, kg | 0.8 |
| Product segment | architectural lighting |
| Control system | On/Off, DMX512, [24V version for external 0-10V/DALI power supply] |
| Protection | IP66 |
| Beam angles | 5°, 8°, 10°, 12°, 15°, 20°, 24°, 36°, 60°, 10×30° |
Housing: Pressure die-cast aluminum with polyester powder paint.
Housing color: Grey, RAL
Beam angles: 5°, 8°, 10°, 12°, 20°, 25°, 30°, 40°, 45°, 60°, 10°×22°, 15°×55°, 20°×60°
IES protection classes: Class I (SELV)
Color temperature, K: 2700K, 3000K, 4000K, 5700K, R, G, B, RGB 3in1, RGBW 3in1
Input voltage, V: 24V, 220V
Control system: On/Off, DMX512, [24V version for external 0-10V/DALI power supply]
Ingress Protection Rating, IP: P66
Operating temperature: -40°С ~ +50°C
Weight: 0.8−3.5 kg
